OVERVIEW
ON THE HEELS OF THE PRO-LEVEL AM 4, THIS EMTB IS NOT OUT OF CONTENTION FOR RACE MEDALS
While sharing the UCI World Cup podium-winning SR Suntour Durolux 36 RC2/TRI AIR 3CR suspension, its XT shifter/derailleur glides along the 10-51 cassette and 30mm-wide MX rims create a slacker ride feel while still providing great contact from the rear tire. 165mm E-Thirteen crank arms stay tucked away from rock strikes and keep you comfortable at higher cadence climbs.
THE NEW BOSCH SMART SYSTEM
THE MOTOR: Performance Line CX
As part of the new Smart System, the Performance CX motor delivers 85 Nm torque. This drive unit is ideal for challenging eMTB rides. The eMTB mode gives you full control and intuitive handling without having to switch between different riding modes. Whether on long climbs or steep descents, the multi-sensor concept and innovative Bosch motor controller enable the Performance Line CX to respond flexibly and with great sensitivity, even on challenging trails.
THE BATTERY: PowerTube 750
PowerTube stands for batteries that are elegantly integrated into the frame. The PowerTube rated at 750Wh is ideal for long day rides. The new battery is slightly larger than the previous ones and thus required a new frame body which was developed in-house from the ground up.
THE DERAILLEUR: Deore XT
Bikers have trusted Shimano XT components for generations. The shifting is stable and precise, offering top performance on almost any surface and making every bike ride a special experience.
THE BRAKES: Deore BR-M6120
Hydraulic disc brakes are characterized by excellent braking performance. The new BR-M6120 ranks particularly well on long descents thanks to its ICE TECHNOLOGY, which relies on Shimano’s cooling technology and better heat dissipation, this avoiding fading. The 4-piston brakes perform excellent even on wet conditions.
TECHNOLOGY
Boost widens the rear and front axle which contributes to a stronger, stiffer, and ultimately more efficient wheel.
The 2022 Smart System Performance CX offers more and better connectivity features and anti-theft protection than its predecedor while maintaining its speed assistance of up to 20 mph and maximum torque of 85 Nm.
Recommended for enduro mountain bikes.
Routing a cable is a thing from the past. Ebike or traditional bike, MonkeyLink connects components and bike with a single click.
This ensures best riding stability and excellent control head stiffness.
The main advantages of this axle are stiffness and strength, which added together results in a safer bicycle.
TSR is a dropper seatpost, which can be remotely controlled from your handlebar, allowing for easier and faster adjustment. It allows for faster shift in the bicycle’s center of gravity when approaching uphills and downhills.
For a clean look and better protection of the cables.
